Drum heaters

Drum heaters and heating belt for heating and maintaining the temperature of metal or plastic drums and containers

Heating belts and drum heaters CETAL are applied to heating and maintaining the temperature of metal or plastic drums and containers containing fluid or viscous products (water, oil, wax, grease, bitumen, tar, etc.).

Product presentation

  • Power from 500W to 2500W
  • Flexible or metallic heating belt

Advantages

  • Robust
  • Easy to install

Operating conditions

  • Normal (non ATEX)
  • Voltage 230V

Metal heating belt

The 2500W metal heating belt allows the heating of viscous products in barrels such as wax, grease, ointment, gelatin, organic acids, bitumen, tar, etc.

Robust, Lightweight, easy to install, this belt with a large heating surface avoids any carbonization of the product (load ≤ 1 W / cm2).

To be placed on the smooth and non-fluted parts at the bottom. The tightening is ensured by a device adjustable to the diameter of the barrel.

Male and female connectors provided, voltage 230V.

Item without thermostat

Power +5-10%

ø to tighten (mm)

Weight (kg)

7507-01

2500W

570-615

6.3

Flexible heating belts

The flexible heating belts, with a power of 300 to 1500 W, consist of an electrical resistance embedded in a silicone panel.

Flexible models, with high mechanical strength, for heating metal drums from 25 to 200 liters depending on the model.

The flexible IP43 heating belts are equipped with an adjustable thermostat 0/120 °C, a 2 m power cable, 230V voltage and hooks and springs for easy and quick installation and removal.

Items

ø to tighten (mm)

Width (mm)

Volume (l)

Power +5-10%

Weight (kg)

7531-03

320-330

125

55

500W

1.5

7531-01

577-605

125

200

1000W

2.2

7531-15

577-605

180

200

1500W

2.2
